Travel time:

4 – 10 sec

Piston stroke:

740 mm

Piston diameter:

40 mm

Rising pushing power:

500 daN

Max. pushing power:

1000 daN

Total weight:

180 Kg

Protection standards:

IP 557

Power output:

1 KW (0.75 HP)

Supply voltage:

230 V

Frequency:

50 Hz

Absorbed current:

2 A

Capacitor :

15 µF

Motor rotation speed:

1450 rev/min

Hydraulic pump:

P10

Hydraulic pump capacity:

9 L/min

Average working pressure:

2 MPa (20 bar)

Maximum supplied pump pressure:

4MPa (40bar)

Working temperature:

–20°C +80°C

Static weight of the pump assembly:

12 Kg
